JDSU Corp.
HST-3000
HST ID : 06EC49000000
Software Version : 6.11.00
*hh:mm:ss 12	mm/dd/yyyy
*02:32:34 PM	08/01/2009
#=========================================
# ADSL Annex A/ATU-R Configuration
Standard:	T1.413
Coding Gain:	On
Auto Sync:	On
Echo Cancellation:	On
Power Cutback:	Off
#=========================================
# ADSL Summary
Modem State:	Show Time
Connected Standard:	T1.413
Upstream  Actual Rate:	384	K
Upstream  Max Rate:	896	K
Upstream  Capacity:	42 %
Upstream  Noise Margin:	23	dB
Upstream  Attenuation:	8	dB
#----------
Downstream  Actual Rate:	1536	K
Downstream  Max Rate:	8128	K
Downstream  Capacity:	18 %
Downstream  Noise Margin:	37.5	dB
Downstream  Attenuation:	18	dB
#=========================================
# ADSL Error
LOCAL LOS:	0
LOCAL SEF:	0
LOCAL RS Corr Bytes:	0
LOCAL CRC:	2
LOCAL OCD:	0
LOCAL HEC:	0
LOCAL NCD:	0
#----------
REMOTE LOS:	0
REMOTE SEF:	0
REMOTE RS Corr Bytes:	0
REMOTE CRC:	0
REMOTE HEC:	0
REMOTE NCD:	0
#=========================================
# ADSL Performance
Upstream  Actual Rate:	384	K
Upstream  Max Rate:	896	K
Upstream  Capacity:	42 %
Upstream  Noise Margin:	23	dB
Upstream  Attenuation:	8	dB
Upstream  Connect Mthd:	Fast
#----------
Downstream  Actual Rate:	1536	K
Downstream  Max Rate:	8128	K
Downstream  Capacity:	18 %
Downstream  Noise Margin:	37.5	dB
Downstream  Attenuation:	18	dB
Downstream  Connect Mthd:	Fast
#----------
Training Time:	9	seconds
Num Syncs:	2
#=========================================
# ADSL Signal
Dn Noise Margin:	37.5	dB
Dn Attenuation:	18	dB
Dn Intl Depth:	1
Dn Tx Power:	18	dBm
Dn Coding Gain:	5	dB
Dn NM - Coding Gain:	32.5	dBm
Up Noise Margin:	23	dB
Up Tx Power:	11	dBm
Up Attenuation:	8	dB
Up Intl Depth:	1
Estimated Length:	3.638	k ft
#=========================================
# ADSL Identity
Modem Firmware:	53050
Modem Revision:	1
Far Vendor ID:	34
Far Vendor Rev:	1
Far Vendor Name:	ALCATEL
